The all new Cinder Cone features updated geometry and revised stem lengths for even more control on the trail. It’s the perfect all-rounder for riders who want to explore off-road or cruise backwoods bike paths with confidence.

A 100mm suspension fork, dependable 11-speed drivetrain, and hydraulic disc brakes deliver performance you can trust. Plus, it’s compatible with up to 27.5x2.3" or 29x2.3" tires for added versatility.

The Cinder Cone is where mountain capability meets everyday functionality - at a great price.

SPECIFICATIONS

FRAME	Kona 6061 Aluminum Butted
SIZES	XS, S, M, L, XL
REAR SHOCK	n/a
FORK	Rockshox Judy Silver 100mm
CRANKSET	Prowheel CHARM 30t 4-bolt 104mm / Length S 165mm / M-XL 170mm
BOTTOM BRACKET	Feimin BSA 73
PEDALS	Kona JS2
CHAIN	KMC XGlide
CASSETTE	Shimano CUES 4000 11-50t 11spd
CHAINGUIDE	n/a
FRONT DERAILLEUR	n/a
REAR DERAILLEUR	Shimano CUES 6000
SHIFTERS	Shimano CUES 6000
BRAKE CALIPERS	Shimano MT200
FRONT BRAKE ROTOR	Shimano 180mm 6B
REAR BRAKE ROTOR	Shimano 160mm 6B
BRAKE LEVERS	Shimano MT200
HEADSET	Feimin ZS44/ZS56
HANDLEBAR	Kona 31.8mm / Back 6º / Rise 20mm / Width S 740mm / M-XL 780mm
STEM	Kona 31.8mm / Rise 7º / Length S-M 40mm / L-XL 50mm
SEATPOST	Kona w/Offset 31.6mm / Length S-M 350mm / L-XL 400mm
SEAT CLAMP	Kona Clamp 34.9mm
GRIPS	Kona Key
SADDLE	Kona MTB
FRONT HUB	Joytech 9x100mm
REAR HUB	Joytech 10x135mm
SPOKES	Stainless 2.0mm Black
RIMS	Double Wall Aluminum
FRONT TIRE	Maxxis Rekon 2.25" (S=27.5", M-XL=29")
REAR TIRE	Maxxis Rekon 2.25" (S=27.5", M-XL=29")
PAINT COLOR	Gloss Bone w/ Black Decals

GEOMETRY

	Size	S	M	L	XL
1	ST Length	380	410	450	490
2	TT Length	587	622	650	687
3	Reach	430	455	480	515
4	Stack	586	624	633	642
5	Standover	699	728	726	721
6	HT Angle	67.5	67.5	67.5	67.5
7	HT Length	110	120	130	140
8	ST Angle	75	75	75	75
9	CS Length	435	450	450	450
10	BB Drop	45	60	60	60
11	BB Height	310	315	315	315
12	Wheelbase	1132	1190	1219	1257
13	Front Center	701	746	755	814
14	Fork Length	490	509	509	509
15	Fork Offset	42	51	51	51

All specifications are subject to change without notice.
Prerelease products may be displayed as graphic representations.
